DD PSU Apple G5 iMac Power Supply Capacitors Kit DD Style

Apple iMac G5 Power Supply "DD" Style (PSU Repair Kit: Capacitors Only)

9 Total Capacitors Listed

Capacitors Replacement Upgrade

• 1200uF (qty. 1) 10mm X 20mm 16 V
• 2200uF (qty. 2) 10mm X 25mm 10 V
• 1000uF (qty. 4) 8mm X 20mm 16 V
• 120uF (qty. 1) 8mm X 15mm 50 V
• 1000uF (qty. 1) 12.5mm X 20mm 35 V

Refer to the list of Apple iMac G5 Power Supplies with detailed pictures and capacitor upgrade replacement comparisons. Be sure to verify which Apple iMac G5 power supply you have.

Capacitors are all high quality, switching power supply grade, low ESR, and long life ratings. These caps have a significantly longer life rating than the originals, and will fit inside the case with no problems. The case actually has approximately 31mm height capabilities from the top of the printed circuit board to the inside of the metal cover. Upgrade notice: I have upgraded some of the capacitors to higher voltage ratings. This was done as a matter of choice, in that a higher voltage is not necessarily required in the power supply, but where appropriate sizes were available in higher voltage ratings, I made the upgrade substitutions for extended performance and life expectancies.

Included with the order is a replacement chart showing the original value capacitor and the replacement value capacitor with your PSU cap order. Please refer to this chart when installing the new caps.

Be sure to double check your mother board capacitors too. Purchase both the MOB and PSU caps, and save on shipping costs.
